200W Outdoor LED Logo Light

Model: LS-L002A-200W-IP

Specification Overview

Optical System

Light Source: 1*200W OSRAM White LED
Color Temperature: 6500-7000K
Optical Angle: 28° 36° 48°( Optional)
Light Source Life: 50,000 hours
Spot Shape: circle/splice Square

Gobo System

4 independent rotation gobos with adjustable speed (Gobos can be customized)

Control & Display

Control Channel: 6 CH
Control Protocol: manual, auto,master/slave
Menu Display: LCD display

Effect

Dimmer: 0-100% linear dimming
Focus: manual electronic positioning function
Smart off-line auto run mode
Intelligent offline control mode
Pre-program the effects in the fixture and when it is power on, it plays automatically

Power Parameter

Voltage: AC110-240V,50-60Hz
Power: Max 220W

Working Environment

Temperature: -25°- +35°

IP Rate

IP 65

Others

Temperature Control: real-time monitoring
Overheat Protection: automatic protection at high temperatures
Internal Protection: electronic moisture-proof processing
Signal Connection: XLR
Cooling System: fan wind cooling
Adjustment Angle: up and down adjustment>180°
Housing Material: die-cast aluminum

Dimension & Weight

Fixture Dimension: 34x30x36CM
Net Weight: 8.5KG

Package

1 set/ carton

** Errors and omissions are possible. All specifications are subject to change without prior notice. **
