200W/230W Moving Head
Model: LS-M003
Specification Overview
Optical System
- Light Source: 7R Osram 230w
Color System
- Color Wheel: 14 color filters+white.Rainbow effect with bidirectional rotation
Gobo System
- Rotation Gobo Wheel: 17 rotation gobos+white circle, pattern shaking
Effect
- Prism: 8 facet prism with rotation in both directions
- Focus: 20 m@50000lux
- Forest: Forest function with wash effect
Movement Parameter
- PAN 540° , TILT 270°
- Interlocks for axis
Control & Display
- Control Channel: 16/20 CH
- Control Protocol: DMX512, master-slave, sound activated, auto
- Menu Display: Touch LCD display screen
Power Parameter
- Voltage: AC110-260V,50-60Hz
- Power: 250W-280W
Working Environment
- Indoor use
IP Rate
- IP 20
Others
- DMX Connector: 3-pin XLR DMX in/out
- Power Connector: Powercon connector
- Housing Material: ABS plastic+ metal
- Housing Color: white and black models for option
Dimension & Weight
- Net Weight: 18 kg
- Package Dimension: 44x41x51cm (1in1 carton,20 kg),82x47x68cm(2in1 flight case,60kg)
** Errors and omissions are possible. All specifications are subject to change without prior notice. **
