12X40W Zoom LED Moving Head
Model: LS-M009-12x40W-Zoom
Specification Overview
Optical System
- Light Source: 12x40w RGBW 4in1 Osram LED
- Light Source Life: 50,000 hours
- Color Temperature: 2800K-8500K
- Flare Angle: 4.5 °-45°
Effect
- Focus: High quiet motor precision focus spot without jitters
- Strobe: 1-20Hz
- Dimming: 0-100% (16bit)
- RGBW Color Mixing and Pixel Control
Movement Parameter
- PAN 540° , TILT 270°
Control & Display
- Control Channel: 12/17 CH(overall), 11/17/18/58 CH(Pixel)
- Control Protocol: DMX512, master-slave, sound activated, auto.
- RDM Function, DMX software upgrade function
- Optional Network Support: Artnet, Klingnet, sACN,network protocol
- Menu Display: Full color 180° reversible LCD menu display
Power Parameter
- Voltage: AC100V-240V,50-60Hz
- Power Consumption: 600w
- Drive current: 2.5A
Working Environment
- Indoor use
IP Rate
- IP 20
Others
Power Connector: PowerCon In/out
DMX Connector: 3-pin XLR DMX in/out
Working Temperature: 0-45°
Intelligent speed fan, real-time display speed Efficient cooling system, full temperature monitoring, over temperature automatic regulation protection, no lamp bead damage risk
Dimension & Weight
- Net Weight: 15 kg
** Errors and omissions are possible. All specifications are subject to change without prior notice. **
