9x15W 6in1 Outdoor Pixel LED Par
Model: LS-P001A-9x15W-6in1-Pixel-IP
Specification Overview
Optical System
- Light Source: 9x15W RGBWA+UV LED
- Light Source Life: 25°/30°/40°
Effect
- Single pixel control(optional)
- Color mixing,static color,color chasing,strobe
Control & Display
- Control Channel: 6/10/54CH
- Control Protocol: standard DMX512, master-slave model, sound activted control, auto operation
- IRC for option (optional)
- Menu Display: LED Or OLED display
Power Parameter
- Voltage: AC90-240V,50-60Hz
Working Environment
- Outdoor use
- Temperature: -20°C- 35°C
IP Rate
- IP 65
Others
- DMX Connector: PG 3pin connector or 3pin connector
- Power Connector: PG 3pin connector or Powercon
- Housing Material: Aluminum alloy
- Housing Color: Black or white
Dimension & Weight
- Fixture Dimension: 255x246x159.5mm
- Net Weight: 7kg
** Errors and omissions are possible. All specifications are subject to change without prior notice. **
